Motion Control – Voice Coil Motor with Internal Shaft and Bearing Features 63.9 lbs of Continuous Force!

Motion Control – Voice Coil Motor



MotiCont-Logo

Van Nuys, CA – Motion Control Components – Moticont has added a new high force voice coil motor to its GVCM family of voice coil motors with an internal shaft and bearing. The new GVCM-095-089-03 Linear Voice Coil Motor (also known as linear DC motor) features a continuous force of 63.9 lbs (284.1 N) and 202.0 lbs (898.4 N) of peak force at a 10% duty cycle. Guided by a long-life plain bearing that can allow side loads up to 3 lb (13.5 N), the precision ground 0.236 inch (6.0 mm) diameter shaft with an internal thread has a stroke length of 0.5 in. (12.7 mm). The quiet, efficient, smooth, cog-free motion of this low inertia brushless GVCM-095-089-03 Linear Voice Coil Motor is ideal for: Clamping, work holding, sorting equipment, assembly, medical devices, antenna positioning, testing, slide actuators, shutters, doors, valve actuation, wafer handling, and optical focusing.

This new voice coil actuator features: High speed, high acceleration/deceleration, zero backlash, high accuracy, high repeatability, and a high force to size in either direction, in a housing measuring just 3.75 in. (95.3 mm) dia. x 3.5 in. (88.9 mm) long. The housing and coil ends of the motor have threaded mounting holes in the housing and coil ends for easy integration into new and existing applications.

Is there a need for a smaller or larger diameter motor, one with longer stroke, or more force? There are currently 7 series of Moticont’s expanding line of GVCM motors based on diameter of the motor, and models based on length of stroke and/or force to select from with additional motors being added to select from. To find the right motor for you application, please visit: http://www.moticont.com/linear-motor-with-bearing.htm

About Moticont – Moticont is a manufacturer of motion control products. Their product line includes voice coil motors, three phase brushless motors and positioning stages and slides.

Moticont is committed to exceeding Our customers’ quality expectations and industry standards throughout the design, manufacturing, service and technical support phases. Our modern manufacturing facility, highly controlled processes, committed staff, and extensive testing complement our product design strengths. This enables us to supply our clients with specialized small orders to high volume just-in-time deliveries.

We offer an extensive line of standard products ready to be shipped immediately from stock, and when standard products are not quite right for an application, highly trained design engineers are always available to develop custom motion control products to fit the specific needs or our customers.

For additional information contact Sales Team at Moticont, 6901 Woodley Ave, Van Nuys, CA 91406; Toll Free: +1 (888) 785-1804, Tel: +1 (818) 785-1800, moticont@moticont.comor visit the website at http://www.moticont.com


For other Motion Control Components, Applications, and Technology from Moticont go to: http://MotionControlBuyersGuide.com


MotiCont-Logo
Visit our Website
Other Products
Videos

Motion Control – AMC introduces the FE060-25-EM – FlexPro™ Digital Servo Drive!

Motion Control – Digital Servo Drive

Motion Control Digital Drive



Motion Control - Electromate-Logo



Vaughan, Ontario, Canada — Motion Control Components — Available immediately, the FE060-25-EM is the first servo drive of the new FlexPro™ digital drive family from ADVANCED Motion Controls (AMC). Designed with compact form and power density in mind, the micro-sized FE060-25-EM can outperform larger-sized digital servo drives and still be integrated into tight spaces.

At just 1.5 x 1 x 0.6 inches (38 x 25 x 16 mm) in size, the footprint of the drive is approximately the same as two standard postage stamps. In other words, four of these drives can fit on a standard business card. Even with its small size, the FE060-25-EM can supply brushed, brushless, stepper, and linear servo motors with up to 25 amps continuous current and 50 amps peak current.

Features include:

  • 1.5 x 1 x 0.6 inches (38 x 25 x 16 mm) in size
  • 10-55 VDC supply voltage
  • 25A continuous current
  • 50A peak current
  • Highest power density servo drive from ADVANCED Motion Controls to date
  • EtherCAT Communication
  • Incremental encoder and BISS C-mode feedback
  • Torque, velocity, and position operating modes
  • Configuration and full loop tuning
  • IMPACT™ architecture

A developer version is available for proof-of-concept and testing purposes – part number FD060-25-EM. It comes with an FE060-25-EM soldered to a larger board that is equipped with various connectors for simplified interfacing.

Projected Industries & Applications:

The small size of the FE060-25-EM makes it perfect for cobots (collaborative robots), AGVs, portable devices, lab and warehouse automation, military equipment, and any other integrated design.

About FlexPro™

FlexPro™ is AMC’s newest family of digital servo drives. With cutting edge engineering, FlexPro™ is meant to expand the capabilities of AMC’s already powerful and diverse product selection. The IMPACT™ architecture allows FlexPro™ servo drives to maintain the intelligence and power of larger-sized servo drives while fitting into much more compact packages. The FE060-25-EM is the first drive in the series with many more to come.

About IMPACT™

IMPACT™ (Integrated Motion Platform And Control Technology) is the architecture that makes AMC’s FlexPro™ drives possible. The stacking of circuit boards with creative selection and placement of high-power components allows for much higher power density than previously produced servo drives. The expanded processing capabilities ensure the drive’s intelligence is unmatched. IMPACT™ makes its debut with the FE060-25-EM. This technology will be used in subsequent FlexPro™ drives as well as any future custom products where it is desired.



About ADVANCED Motion Controls

ADVANCED Motion Controls, a U.S. company in business for over 31 years, was founded with the idea of designing and manufacturing lower cost / higher power density servo drives. The company’s focus remains to create and deliver the best motion control drives for brushed or brushless servo motors. With approximately 3 million servo axes shipped, ADVANCED Motion Controls has become one of the fastest growing servo drive companies in the world.

CLICK HEREFor information on the FE060-25-EM from Advanced Motion Controls can be viewed at:

About Electromate:

Electromate’s Core Purpose is to help Manufacturers build better machines using differentiated automation technology. They specialize in Robotic and Mechatronic Solutions for the Industrial Automation marketplace. Respected by customers as a premiere source for High Performance Automation and Motion Control Components & Systems, Electromate® specializes in AC & DC Servo and Stepper Motors & Drives, Motion & Automation Controllers, Positioning Systems & Actuators, Feedback Devices, Gearing Products and HMI’s & Operator Displays, all supported via extensive product selection, just-in-timedelivery, dedicated customer service and technical engineering support.

More on Electromate can be found at

Website: http://www.electromate.com

LinkedIn: https://www.linkedin.com/company-beta/209277/

Twitter: https://twitter.com/Electromate

Facebook: https://www.facebook.com/electromateindustrial/

Google+: https://plus.google.com/104057418684128701566

Blog: https://electromate.wordpress.com/

Electromate Best Blace to Work

For more information on the “Best Place to Work”CLICK HERE!

To view Electromate’s new corporate video CLICK HERE

To see all of Electromate’s Products and Application Stories featured on MotionShop.com, enter electromate in the Google custom search box (upper left, above)

For further information on this new product or others in our extensive product portfolio, call 1-877-SERVO99 (737-8699) or e-mail Warren Osak at sales@electromate.com or visit Electromate at: www.electromate.com

See this and other Motion Control Components from Electromate featured on:
http://MotionShop.com
http://AllMotionBlogger.com
http://Automation-Blogger.com
http://MotionControlBlogger.com
http://MotionControlWeb.com
http://MotionShop.net



Motion Control - Electromate-Logo
Visit our Website
Motion Control - Electromate Twitter Link
Motion Control - Electromate Facebook Link

Motion Control Air Bearing Stages from H2W Technologies

Motion Control – Air Bearing Stages
Motion Control Air Bearing Stage

Motion Control H2W

The ABS positioning stage is a high precision, granite base, air bearing positioning stage for high end positioning applications. It is driven by an ironless core, non-cogging 3 phase brushless linear motor and guided by 5 flat magnetically preloaded air bearings floating on a granite base. The ironless core coil assembly is used as the drive mechanism for the AB stage because of its smooth, non-cogging operation. The lightweight of the coil and table assembly allows for high acceleration of light loads. The air bearings, which are used for supporting and guiding the payload, float on a cushion of air. This ensures that there are no wearing components in the system. The air bearings are not limited to acceleration limits like their mechanical counterparts where balls and rollers can slide instead of roll at high accelerations. The stiff cross section of the granite base of the stage ensures a flat straight stable platform for the payload to ride on and does not require any special mounting considerations. Bellows (folded way covers) with a 12:1 extension to compression ratio may be added to an ABS stage. The power for the moving 3 phase coil assembly, encoder and limit switches is routed through shielded flat ribbon cable. Special consideration was made to separate the power and signal cables from each other to reduce the effects of noise on the system. The power cable for the coil assembly and a vacant cable for the customers payload power usage are installed on one side of the stage and the encoder signal, limit switch and an additional vacant signal cable for the customers payload signal usage is provided on the other side of the stage. Standard connectors are provided. The ABS positioning stage incorporates the latest in linear motion technology:

  • Motors: Non-contact 3 Phase Brushless Linear Motor, Ironless Core, commutated either sinusoidally or trapezoidally with Hall Effects. The encapsulated coil assembly moves and the multi pole permanent magnet assembly is stationary. The lightweight coil assembly allows for higher acceleration of light payloads.
  • Bearings: Linear guidance is achieved by using magnetically preloaded, porous carbon or ceramic air bearings; 3 on the top surface and 2 on the side surface. The bearings are mounted on spherical surfaces. Clean, dry filtered air must be supplied to the moving table of the ABS stage.
  • Encoders: Non-contact glass or metal scale optical linear encoders with a reference mark for homing. Multiple reference marks are available and are spaced every 50 mm down the length of the scale. Typical encoder output is A and B square wave signals but sinusoidal output is available as an option
  • Limit Switches: End of travel limit switches are included at both ends of the stroke. The switches can be either active high (5V to 24V) or active low. The switches can be used to shut down the amplifier or to signal the controller that an error has occurred. The limit switches are typically an integral part of the encoder, but can be mounted separately if required.
  • Cable Carriers: Cable guidance is achieved by using flat, shielded ribbon cable. Two additional unused shielded flat ribbon cables are supplied for customer usage with the stage. The 2 power cables for the stage and customer payload are installed on one side of the stage and the 2 signal cables for encoder, limit switch and customer payload are installed separately on the of the stage.
  • Bellows: The ABS comes standard with neoprene / nylon bellows with Mylar stiffeners.
  • Hard Stops: Hard stops are incorporated into the ends of the stage to prevent over travel damage in the event of servo system failure.

               Advantages:

Motion Control – ZrO2 Zirconia Ceramic Radial Ball Bearings For High Loads available from LM76 are FDA/USDA/3A-Dairy Compliant!

Motion Control – Zirconia Ceramic Radial Bearings
motion control radial bearings

motion control - LM76

E. Longmeadow, MA — Motion Control – LM76 has announced the release of their new line of Radial Ball Bearings featuring ZrO2 (Zirconia) Ceramic balls. To Complement LM76’s broad range of Linear Bearings that are FDA/UDSA/3A Dairy compliant, as well as linear bearings for extreme environments; they have added Deep Groove bearings which accommodate radial and axial loads, Angular Contact bearings for simultaneously handling radial and axial loads, Spherical Bearings which are self aligning, and Thrust Bearings for high axial loads. Each of the four types of metric bearings are available in a wide range sizes.

The advantages of ZrO2 ceramic balls are: FDA/USDA/3A Dairy/Caustic washdown compliant, lighter than steel balls and can be used at extreme RPMs, they withstand higher loads without spalling, have a lower coefficient of friction, are inert to chemicals, have no magnetic signature, and are non conductive.

With the addition of these radial bearings with ZrO2 Ceramic balls LM76 has increased “The Engineering Edge” it has in providing bearings and components for FDA/USDA, Medical, Bio/Pharma, Aerospace, Marine, and other out-of-the-box applications. These bearings have a working temperature range of -80OC to 400OC, they will not deform under load, and require no lubrication.

Shafting options include: Solid and hollow Class L RC60, 300 series stainless steel in lengths to 12 feet. FDA/USDA/3A-Dairy compliant, shafting features: Excellent corrosion and chemical resistance, custom machining to print, pre-drilling and assembly.

To follow the NEW Series from LM76, THE ENGINEERING EDGE! and learn about interesting Outside-of-the-Box solutions developed by LM76 to solve some interesting linear motion problems! CLICK HERE

About LM76

Founded in 1976, LM76 has been a leading designer/manufacturer of linear bearings, slides and linear motion systems. LM76 is renowned for its industry leading Minuteman PTFE Composite linear bearings. LM76 is a leading supplier of precision linear shafting: RC60, 300 Series Stainless Steel, and ceramic-coated aluminum shafting. LM76 also offers several FDA/USDA compliant linear bearings and slides for the food processing, pharmaceutical, medical, and packaging industries.

See this and other Motion Control Components from LM76 featured on:
http://MotionShop.com
http://AllMotionBlogger.com
http://Automation-Blogger.com
http://MotionControlBlogger.com
http://motioncontrolBuyersGuide.com
http://MotionControlWeb.com
http://MotionShop.net

For additional information contact Mike Quinn at: LM76, 140 Industrial Dr., E. Longmeadow, MA 01028; Telephone: 413-525-4166, Fax: 413-525-3735 or E-Mail: mquinn@lm76.com or visit the website at http://www.lm76.com

And say, “I saw it on MotionShop.com, “The Motion Control Home Page.”


For other Motion Control Components, Applications, and Technology from LM76 go to: http://AllMotionBlogger.com


LM76
Visit our Website
Order Our Catalog

Motion Control – EC-i 52XL 200W High Torque Brushless Servo Motor from Maxon!

Motion Control – Brushless Motor

motion control miniature brushless motor



Motion Control - Electromate-Logo

The motion control EC-i 52XL 200W Brushless Servo Motor from maxon is a powerhouse.  When space is limited but high torque and dynamics are required, the maxon EC-i 52XL motor is the ideal motor choice..

Vaughan, Ontario, Canada — Motion Control Components — With its extended length (80 ? 110mm), this motor with flux collector rotor provides outstanding torque performance compared to the existing EC-i 52 180W High Torque that is often needed, especially on the industrial automation front.

Its extra power can be even more significant at relatively low speed which makes it a powerful fit to a variety of industrial applications including material handling & transport systems.

Because of its optimized magnet ring, the brushless EC-i 52XL motor with an iron winding offers a very high torque density and a low cogging torque.  The multi-pole internal rotor is extremely dynamic.  Its solid design, with a steel flange and steel housing, makes this motor a robust solution for industrial applications.

Features include:

  • Cost-effective
  • 200 Watt Rated
  • 24, 36 & 48VDC windings
  • 8 pole pairs
  • Optional gearheads, encoders and drive electronics

Order your EC-i drive online now at-

EC-i 52XL 200W Brushless Servo Motor Buy Online

Information on the EC-i 52XL 200W Brushless Servo Motor from maxon can be viewed at:

EC-i 52XL 200W Brushless Servo Motor Specification

About Electromate:

Electromate’s Core Purpose is to help Manufacturers build better machines using differentiated automation technology. They specialize in Robotic and Mechatronic Solutions for the Industrial Automation marketplace. Respected by customers as a premiere source for High Performance Automation and Motion Control Components & Systems, Electromate® specializes in AC & DC Servo and Stepper Motors & Drives, Motion & Automation Controllers, Positioning Systems & Actuators, Feedback Devices, Gearing Products and HMI’s & Operator Displays, all supported via extensive product selection, just-in-timedelivery, dedicated customer service and technical engineering support.

More on Electromate can be found at

Website: http://www.electromate.com

LinkedIn: https://www.linkedin.com/company-beta/209277/

Twitter: https://twitter.com/Electromate

Facebook: https://www.facebook.com/electromateindustrial/

Google+: https://plus.google.com/104057418684128701566

Blog: https://electromate.wordpress.com/

Electromate Best Blace to Work

For more information on the “Best Place to Work”CLICK HERE!

To view Electromate’s new corporate video CLICK HERE

To see all of Electromate’s Products and Application Stories featured on MotionShop.com, enter electromate in the Google custom search box (upper left, above)

For further information on this new product or others in our extensive product portfolio, call 1-877-SERVO99 (737-8699) or e-mail Warren Osak at sales@electromate.com or visit Electromate at: www.electromate.com



See this and other Motion Control Components from Electromate featured on:
http://MotionShop.com
http://AllMotionBlogger.com
http://Automation-Blogger.com
http://MotionControlBlogger.com
http://motioncontrolBuyersGuide.com
http://MotionControlWeb.com
http://MotionShop.net

Motion Control - Electromate-Logo
Visit our Website
Motion Control - Electromate Twitter Link
Motion Control - Electromate Facebook Link

Motion Control Application – Maxon Drives Power – Hull Cleaning Robot for Large Ships!

Motion Control Application – Hull Cleaning Robot
Motion Control Application – Specially designed robotic crawler navigates around the underwater portion of a ship to remove the biofilm layers that accumulate there. As a battery operated, autonomous vehicle, component selection made up a highly critical part of the design and manufacture.

Maxon Logo
Visit our Website
Order Our Catalog

motion control application

The HullBUG provides grooming of the biofilm that collects on the
underwater portion of ships. © 2011 SeaRobotics

Fall River, MA — Motion Control Components Application – Toxic paint is used on the bottoms of large ships to prevent fouling, which is when a biofilm layer develops, decreasing the ship’s efficiency in moving through the water. The toxic paint continually leeches copper and other heavy metals into the underwater environment as well, causing damage to the organisms that live there. To further complicate the matter, the paint must be blasted off and replaced every 5 to 10 years, at which time literally tons of toxic waste is produced and needs to be disposed of. A ship that operates with a clean underwater surface free from fouling—even thin biofilm layers—will operate so much more efficiently that potential savings can easily reach over five percent in fuel costs alone. Without the concern for fouling, a ship’s underwater coating can be engineered for corrosion protection and longevity rather than its need to eliminate the potential for biofouling. If realized on all the ships operating in the world today the energy savings would greatly reduce the presence of greenhouse gases, as well.

To eliminate the requirement for toxic paint and its cleaning waste, there needed to be a method to “groom” the biofilm from the underwater portion of a ship. The idea was to create important changes for the ships being built as well as for the environment. That is where the HullBUG (Hull Bioinspired Underwater Grooming) concept originated. “The most important feature of the HullBUG is its small size,” according to SeaRobotics Research Engineer, Dr. Kenneth Holappa. “It is only about half a meter in length. This was a necessary design feature, needed to allow the vehicle to maneuver over the curved surface of the hull while continually maintaining close contact with the surface.

This close-up of the HullBUG clearly shows its sensor alignment
system that helps it keep on course while cleaning a hull.

© 2011 SeaRobotics

Because there are hazards associated with operating such a device underwater and in a harbor environment occasionally a HullBUG might be lost or destroyed during operation. Keeping the size and cost of the system low definitely helped to eliminate damage as a major obstacle to implementation. So, from the very beginning of the project, small size and low cost have been identified as being critical to the satisfactory implementation of the HullBUG project. As can be expected, this need to maintain a particular size and weight filtered into the selection of every component of the design.

Motion Control Components

The selection of the motors to drive the HullBUG involved a number of critical engineering constraints and compromises. SeaRobotics decided to make two basic models, one with wheels and one with tracks, and offer several options for keeping track of the system’s progress, which will be discussed later. Sizing of the motors, for example, required a calculated estimate of the power, speed, and torque characteristics of the manufactured devices. Determining factors included the resistance caused from pushing the grooming tool across the surface of the ship, the hydrodynamic resistance of the vehicle itself as it moved through the water, friction losses in the shaft seals that were used to protect the motors from the saltwater, and track or wheel friction dependent on which version of the unit was used.

In this close-up you can see the max-on EC45 brushless motor and
interface boards about to be safely mounted inside the machine.
© 2011 SeaRobotics

maxon motors offers a full line of fractional horsepower moving coil DC motors and brushless motors ranging in size from 6mm to 90mm, and from 30 mW to 500 watts. They also offer gearheads, controllers, and accessories. “The breadth of their product line and quality of their service helped us to feel comfortable that we had selected the right partner,” Ken said. Flat motors manufactured by maxon Precision Motor provide long life along with their low profile package. The entire EC series of brushless motors are electronically commutated, which enables them to have extremely long motor life since there are no mechanical brushes to wear out. The motors incorporate ball bearings or ruby bearings that also add to the longevity of the motors, especially needed in such harsh conditions. The flat motors were designed specifically for robotics applications where size and weight are important selection criteria. The EC45 flat motors selected for the HullBUG are very efficient and weigh only 75 grams. Continuous output power is 30 watts, while the maximum speed is 10,000 rpm (much faster than what was needed for this application). The important specification for this application was torque. Even under the potentially harsh environments that the HullBUG would be engaged in, the EC45 offered a maximum continuous torque up to 56.2 mNm depending on the winding chosen by the user. The Maxon brushless motors are built to IP54 standards, which was important to the application. Furthermore, the motors were also available in the system voltage that SeaRobotics required for the HullBUG application.

According to Ken, “The large load capacity of the shafts of the GP42 gearhead allowed the wheels to directly mount to the gearhead shaft, greatly reducing the complexity of the overall design of the system.” Gearheads manufactured by maxon are available in a wide range of ratios to enhance speed reduction and/or torque multiplication dependent on the needs of the user’s application. Concentric input and output helped to facilitate simpler and more direct mounting arrangements, as well.

Given that the HullBUG vehicle was to be completely autonomous, it had to be designed in such a way as to operate for many hours on batteries (cables would simply get in the way of the grooming operation). In order to maximize battery life, the grooming of the biofilm had to be performed in the most efficient manner possible. Navigating in a random pattern may eventually get the job done, for instance, but not in a reasonable amount of time. Plus, a typical ship presents a very large underwater surface, often as upwards of three thousand square meters. To keep this amount of area groomed it is expected that a user would employ multiple HullBUG vehicles to operate at the same time and, consequently, require a method of acquiring sophisticated coordinated navigation.

Navigating the HallBUG

A toolset of navigation modes has been created to allow multiple HullBUGs to efficiently groom a ship by dividing the ship’s underwater surface into regions. Numerous algorithms have been incorporated to accurately groom the ship in steps down to the turn of the bilge. Additional algorithms and associated sensors are used to allow efficient grooming of the flat bottom of the ship. Miniature acoustic ranging sonar (MARS) is also an option for navigation control of the HullBUG. This is where a very small close range, pencil beam sonar was specifically developed to allow the vehicle to “see” an upcoming wall or cliff condition such as bilge keels and bow thrusters. Yet another mode of navigation uses a MEMS rate sensor for navigation information. Another feedback mode uses encoder based odometry. Hall sensor feedback from the motor is used as an encoder signal to establish an accurate estimate of odometry. Hall sensors were used instead of optical encoders because of size and cost. The Hall sensors provide better than 1mm accuracy in the measurement of odometry with the motor/gearhead combination chosen.

Ongoing Software Development

An autonomous vehicle is often software heavy in terms of engineering efforts once you’ve selected and implemented the proper motion control system. Getting smooth reliable navigation maneuvers that result in accurate positioning in a widely varying environment was one of the more difficult challenges for the design team. Multiple layers of software were necessary for handling the number and variety of possible events that can occur during grooming. And, the proper organization of the control logic to allow extensibility of navigation behavior was the most difficult part of this complex system. “Software development will continue to be an ongoing effort even after the years already put into it,” Ken said. “Though the vehicle is completely operational, there remains a considerable amount of on-ship testing to be done.” As the project moves forward and into the field, there will no doubt be additional issues that will crop up and need to be addressed, as well. Even now, the vehicle must be able to reliably accomplish its task in a hostile environment and in an unmapped terrain. Then it has to be able to return to the waterline of the ship for retrieval.

This operation must be done repeatedly for days, months, and years, and with multiple systems in the water at the same time. Although this sounds as though it is overly difficult, according to Ken, “A technician was recently trained to use the vehicle and was fully competent within a short period of time. The user interface was borrowed from SeaRobotics’ Unmanned Surface Vehicle (USV) product line and presented an intuitive graphics-driven interface that has hundreds of hours of use by many different customers.” The vehicle is operational and the navigation software is working. The next primary focus will be the structuring of the interface to improve ease of use and allow non-engineering personnel to manage operations.

maxon manufactures a wide variety of EC flat motors for different
kinds of applications. © 2011 maxon motor

Contact maxon for more details info@maxonmotorusa.com

Comprehensive documentation and software are included with every delivery, and are also available for you to download from our website at www.maxonmotor.com.

Maxon Handbook Banner


See this and other Motion Control Components from H2W Technologies featured on:
http://MotionShop.com
http://AllMotionBlogger.com
http://Automation-Blogger.com
http://MotionControlBlogger.com
http://motioncontrolBuyersGuide.com
http://MotionControlWeb.com
http://MotionShop.net





1.50″ Diameter Linear Voice Coil Motor with a 0.75″ Stroke Is Vacuum Compatible!

Motion Control – Vacuum Compatible Voice Coil Motor
motion control vacuum compatible voice coil motor

MotiCont-Logo

Van Nuys, CA – Motion Control Components – Moticont has added a vacuum compatible voice coil motor to its line of linear DC motors. This vacuum compatible, clean, brushless, quiet, efficient, low inertia, high acceleration, high speed linear DC voice coil motor has zero cogging and features high accuracy, and high repeatability when operated in a closed loop as a DC servo motor. The new LVCM-038-038-01-VAC Vacuum Compatible Linear Voice Coil Motor has a stroke length of 0.75 in. (19.1 mm) with a high force-to-size ratio of 3.0 lb (13.4 N) and a peak force of 9.5 lbs. (42.5 N) at a 10% duty cycle.

The motor features two 8-32 UNC-2B threaded mounting holes in the housing and two 8-32-UNC-2B threaded mounting holes on the coil end for easy integration into new and existing applications. Also called a moving coil motor, the compact 1.50 in. (31.8 mm) diameter LVCM-038-038-01-VAC Vacuum Compatible Linear Voice Coil Motor is ideal for: Medical devices, scanners and laser beam steering and filtering, work holding and clamping, testing, wafer handling, optical focusing, in vacuum applications.

Complete plug-and-play systems including an encoder and servo controller are available. Is there a need for a smaller or larger diameter motor, one with longer travel, or more force? There are more than 12 in the expanding series of Moticont’s LVCM linear motors based on diameter of the motor, and over 50 models based on length of stroke and/or force to select from. To find the right motor for your application go to http://moticont.com/voice-coil-motor.htm

About Moticont – Moticont is a manufacturer of motion control products. Their product line includes voice coil motors, three phase brushless motors and positioning stages and slides.

Moticont is committed to exceeding Our customers’ quality expectations and industry standards throughout the design, manufacturing, service and technical support phases. Our modern manufacturing facility, highly controlled processes, committed staff, and extensive testing complement our product design strengths. This enables us to supply our clients with specialized small orders to high volume just-in-time deliveries.

We offer an extensive line of standard products ready to be shipped immediately from stock, and when standard products are not quite right for an application, highly trained design engineers are always available to develop custom motion control products to fit the specific needs or our customers.

For additional information contact Sales Team at Moticont, 6901 Woodley Ave, Van Nuys, CA 91406; Toll Free: +1 (888) 785-1804, Tel: +1 (818) 785-1800, moticont@moticont.comor visit the website at http://www.moticont.com


See this and other Motion Control Components from Moticont featured on:
http://MotionShop.com
http://AllMotionBlogger.com
http://Automation-Blogger.com
http://MotionControlBlogger.com
http://motioncontrolBuyersGuide.com
http://MotionControlWeb.com
http://MotionShop.net





MotiCont-Logo
Visit our Website
Other Products
Videos

Motion Control – Three-axis Gimbal Mount from OES Features High Resolution and Stability from OES!

Motion Control – 3 Axis Gimbal Mount
motion control 3 axis gimbal mount



OES Logo

Van Nuys, CA – -Motion Control Components – The New AU300-AER three-axis Gimbal Mount from OES (Optimal Engineering Systems, Inc.) features full 360O rotation of each axis. This three-axis gimbal mount handles loads to 10kg (22.5 lbs) and has a clearance of 300 mm x 300 mm, (11.8 in. x 11.8 in.) around the roll axis stage. The Azimuth stage rotary table is mounted on a large 360 mm (14.173 in.) x 360 mm (14.173 in.) x 13 mm (0.512 in.) plate with handles and has predrilled accessible mounting holes for easy integration into new or existing applications, and for increased stability. The AU300-AER three-axis Gimbal Mount is ideal for mounting: cameras, optics, lasers and instrumentation for scanning, tracking, positioning, pointing, and other applications.

The 3 axes: azimuth, elevation, and roll axes are drived by bi-directional stepper motors capable of microstepping, and has knobs for manual adjustments. The roll axis table measures 100 mm (3.937 in.) in diameter. The knobs may be replaced with optical encoders for position verification and closed loop positioning. Each axis features: low backlash worm gear drives and precision “V” groove and cross roller bearings for very high resolution of 3.6 arc seconds, and repeatability and positional accuracy to 36 arc seconds. Travel speed of each axis is 8 O per second. Electrical connections are made using three 9 pin DB-9 connectors.

The motion control AU300-AER Motorized Three-axis Gimbal Mount can be ordered as a complete plug-and-play system with a multi-axis controller, joy stick, track ball, or keypad, and with a 30 mm thru hole in the roll stage.

About OES – Optimal Engineering Systems, Inc. (OES) is a manufacturer of motion control products including: Stepper motor controllers and drivers, solenoid electronics, and positioning stages and slides. Applications include: Animation, automated assembly systems, automation, CNC machines, flight simulation, inspection systems, linear and rotary stages, machine tools, medical devices, motion control camera boom systems, optical comparators, CMMs, pan-tilt gimbals, PCB assembly & inspection, pick-and-place, positioning stages, robotics, scanners, security cameras, telescope drive mechanisms, time-lapse photography and winders.

Some of the industries OES serves are: Aerospace, Astronomy, Chemical, Communications, Educational Institutes, University, Colleges, Government Agencies, National Labs, Manufacturing, Medical, Metrology, Military, Motion Control, Museum, News Agencies, Semiconductor and Test Equipment. Optimal Engineering Systems, Inc’s. competitive advantage is its state-of-the-art in-house manufacturing facility in North America enabling OES to supply clients with custom designed orders or high volume just-in-time deliveries globally.

For additional information, contact sales team at: OES, 6901 Woodley Ave.; Van Nuys, CA 91406; Telephone: 888-777-1826 or +1 818-222-9200, FAX +1 818-436-0446 or E-Mail: sales@oesincorp.com or visit the website at http://www.oesincorp.com


See this and other Motion Control Components from OES (Optimal Engineering Systems) featured on:
http://MotionShop.com
http://AllMotionBlogger.com
http://Automation-Blogger.com
http://MotionControlBlogger.com
http://motioncontrolBuyersGuide.com
http://MotionControlWeb.com
http://MotionShop.net

OES Logo
Visit OES Website
OES Facebook
OES Twitter
OES Videos



Motion Control – Gam Gear’s Washdown Servo Gearboxes Available from Servo2Go!

Motion Control – Washdown Gear Heads
motion control washdown gearboxes



Servo2Go-Logo



Greenville, DE —-Motion Control Components – Gam Gear’s new SSP Series is an innovative washdown servo gearbox solution designed for food, medical or sanitary applications. It is a precision inline planetary gearbox outwardly constructed of 300-series stainless steel. The motor adapter plate, housing and shaft are all stainless steel. Viton® seals, stainless steel hardware and sealed interfaces provide outstanding corrosion resistance in all types of wet and caustic washdown environments. Ideal for any light or demanding servo application where corrosion resistance is a requirement, the SSP Series offers economy, high precision, and long lasting performance.



Features of Gam Gear’s washdown Motion Control Servo Gearbox include:

  • Dual output bearings for high radial and axial loading
  • Frame sizes from 70 mm to 120 mm
  • Ratios from 3:1 to 100:1
  • Input clamping element for fast and easy mounting
  • Optional input O-ring to keep contaminants out custom designed for your motor. (Special request at time of order)
  • Optional stainless steel output coupling KG-VA for corrosion resistant
  • 10,000km (400 million inches) standard minimum life



Information on the Gam Washdown Servo Gearboxes available from Servo2Go.com can be viewed at:https://www.servo2go.com/pub/media/wysiwyg/pdfs/Catalog/gam-gear-ssp-series-catalog.pdf

These and other Motion Control Products are available through www.Servo2Go.com

For further information on this new product or others in our extensive product portfolio, call 1- 877-378-0240 or e-mail Warren Osak at warren@servo2go.com or visit Servo2Go.com at: www.Servo2Go.com


See this and other Motion Control Components from Servo2Go featured on:
http://MotionShop.com
http://AllMotionBlogger.com
http://Automation-Blogger.com
http://MotionControlBlogger.com
http://motioncontrolBuyersGuide.com
http://MotionControlWeb.com
http://MotionShop.net

Servo2Go-Logo
Visit our Website
Twitter Link
Facebook Link

Motion Control – Linear Servo Controller Amplifier to Control Voice Coil Motors

Motion Control – Linear Servo Controller/Amplifier

Forestville, CA,   —  Motion Control Components – The SCA814 Linear Servo Controller was specifically designed to control single phase, non-commutated devices like voice coil motors.  like it’s field proven predecessor the SCA754 is a high performance single axis DC motor controller and amplifier system.  It is comprised of a highly integrated single PC board level product with a cohesive interface.  This card provides current amplification and analog servo control interfaces.  The single-phase characteristic of the current amplifier makes it particularly well suited for DC motors such as galvanometers and voice coils.  It was specifically developed for control of motor applications requiring both high temporal and spatial servo precision, such as machine vision, inspection, scientific imaging, medical imaging and other business applications.  This amplifier interfaces directly to many of the Equipment Solution motor/stage solutions.
Besides galvanometers the SCA814 is directly compatible with all the ESI linear voice coil stages and the optical scanners.  A bipolar linear or switching regulated power supply is required by the SCA814 amplifier.  Typically better performance can be achieved when using a linear power supply.  Equipment Solutions has several high-current supplies for this purpose including the SPS15 ±15V DC Switching Power Supply .

Click Here for

  • Specifications
  • Servo Diagram
  • Interface Drawings
  • Downloads

Equipment Solutions, Inc. (ESI) is a provider of engineering and manufacturing services. ESI specializes in the design and production of automation and instrumentation products including motion control components and sub systems. ESI’s products range from galvanometer amplifiers with an integrated arbitrary waveform generator, to high-resolution displacement sensors, voice coil and stepper motor stages, amplifiers and controllers.

For additional information contact Jeff Knirck at Equipment Solutions,Inc. Mailing Address – PO Box 159, Forestville, CA 95436; Shipping Address 6490 Front Street, Forestville, CA 95436; Tel: 408-245-7162, Fax: 408-245-7160, E-Mail: info@equipsolutions.com or visit the Website at http://www.equipsolutions.com



See this and other Motion Control Components from Equipment Solutions featured on:
http://MotionShop.com
http://AllMotionBlogger.com
http://Automation-Blogger.com
http://MotionControlBlogger.com
http://motioncontrolBuyersGuide.com
http://MotionControlWeb.com
http://MotionShop.net



Visit our Website
Motion Control - Follow Equipment Solutions on Twitter
Motion Control - Follow Equipment Solutions on Facebook
View Equipment Solutions Motion Control Blog
