Motion Control Buyers Guide

Motion Control – Electric Cylinders!

Van Nuys, CA – Motion Control – New, Metric and Imperial dimensioned Electric Cylinders or Linear Voice Coil Servo Actuators have been released by Moticont. The new, compact 25.4 mm (1.000 in.) stroke SDLM-025-095-01-01M and SDLM-025-095-01-01 Linear DC Servo Actuators feature high repeatability, high acceleration/deceleration, and zero cogging! These high force-to-size Electric Cylinders have linear encoders mounted internally for closed loop servo operation. Additionally, to operate at peak efficiency, integral temperature sensors provide data to achieve the highest possible throughputs.

The clean fully enclosed SDLM-025-095-01-01M and SDLM-025-095-01-01 Servo Actuators are 25.4 mm (1.000 in.) in diameter, the housing is 95.3 mm (3.750 in.) long and the total length of the housings and shafts are 139.7 mm (5.500 in.).

Motion Control – Linear Servo Controller

Forestville, CA, – Motion Control – The SCA814 Linear Servo Controller was specifically designed to control single phase, non-comutated devices like voice coil motors. like it’s field proven predecessor the SCA754 is a high performance single axis DC motor controller and amplifier system. It is comprised of a highly integrated single PC board level product with a cohesive interface.

This card provides current amplification and analog servo control interfaces. The single-phase characteristic of the current amplifier makes it particularly well suited for DC motors such as galvanometers and voice coils.

Motion Control – USDA Certified Stand-Off Bearing Flange Blocks

E. Longmeadow, MA – Motion Control – FDA/USDA Certified, two, three and four post, Stand-Off Bearing Flange Blocks are setting a new standard for performance and Hygienics. These new Stand-off bearing flange blocks now available from LM76 reduce the surface area where mold and bacteria can thrive, even from the most through sanitizing operations. Long life Hybrid Stainless Steel Si3N4 Silicon Nitride Ceramic Ball Bearings in Stainless Steel bearing blocks are coated with a smooth non-water absorbing polyamide coating certified by EHEDG, USDA, and 3-A.

Innovative Motion – ZGG Stage – Lift Plus Dual Goniometers

Van Nuys, CA – Innovative Motion – New High Precision Three-axis ZGG-60-10-15 Series of Lift, Pitch, and Roll Stages have been released by Optimal Engineering Systems, Inc. (OES). These compact stages feature 60 mm +/- 2 mm (2.362 in. +/- 0.078 in.) of vertical travel.

See the ZGG Stage in Action Click on the Youtube Link –  https://youtu.be/I7YQ3LycIwA

Motion Control – Sub-micron Positioning Stage

Forestville, CA, —motion control  — High speed, high force, sub-micron, >300 nanometer (1.1811 10-6 in.) positioning resolution, cross roller voice coil stages are self contained, compact, and can be mounted in a horizontal or vertical axis. The high speed, 20 mm (0.7874 in.) travel, Equipment Solutions’ Motion Control VCS-2020 Voice Coil Stage features a 20 mm dia. aperture.

An integrated Analog position feedback sensor assures 100 nanometer (3.937 10-6 in.) repeatability. This compact voice coil stage is ideal for such micro-positioning applications as: Scanning interferometry, disk drive testing, auto focus systems, surface structure analysis, confocal microscopy, biotechnology, and semiconductor test equipment.

Motion Control – Facebook Pages – Companies

MotionShop.com invites you to check out these Company Facebook pages …

https://www.facebook.com/LM76Blogger/

https://www.facebook.com/OESMotionSystems/

https://www.facebook.com/Moticont/

https://www.facebook.com/electromateindustrial/

https://www.facebook.com/MagneticSensorSystems/

https://www.facebook.com/EquipmentSolutions.Blog/

Check out these other Motion Control Facebook Pages as well:

https://www.facebook.com/MotionControlHomepage/
https://www.facebook.com/InnovationsinMotionControl/
https://www.facebook.com/AllMotionBlog/
https://www.facebook.com/AutomationBlogger/
https://www.facebook.com/MotionControlBlogger/
https://www.facebook.com/MotionControlBuyersGuide/
https://www.facebook.com/MotionControlWeb/
https://www.facebook.com/MotionControlMktg/
https://www.facebook.com/XYZinMotion/
https://www.facebook.com/EquipmentSolutions.Blog/
https://www.facebook.com/LM76Blogger/

See these and other Motion Control Components featured on:

http://MotionShop.com.com

http://MotionControl-XYZ-Theta.com

http://LinearMotionBlogger.com

http://AllMotionBlogger.com

http://Automation-Blogger.com

http://MotionControlBlogger.com

http://motioncontrolBuyersGuide.com

http://MotionControlWeb.com

http://MotionShop.net

http://Catalogs-MotionControl.com

Motion Control – Four-axes Linear, Pitch, Roll, and Roll Stages

Van Nuys, CA – Motion Control – The new Motion Control XGGR-50-10-15-60 Series of Four-axis Linear, Pitch, Roll, and Yaw Stages from OES (Optimal Engineering Systems, Inc.) is the integration of a Linear-axis stage, two Goniometer Stages, and a Rotary Stage. The lower Linear axis stage has 50 mm of travel. The Pitch-axis is a +/- 10 degrees Goniometer, the Roll-axis is a +/- 15 degrees Goniometer, and the Yaw-axis (upper -axis) is a 60 mm diameter rotary stage capable of continuous rotation. These compact four-axis Linear, Pitch, Roll, and Yaw stages feature four motor options to meet the precision and speed of travel requirements of an application.

Watch on YouTube– https://youtu.be/2ymH0TjI3Vc

Motion Control – Linear Focus Actuator

Forestville, CA – Motion Control – The LFA-1205 Linear Focus Actuator is a high performance compact positioning system.  It was specifically developed for optical applications requiring both high precision and high-speed positioning over a short to medium stroke.

The LFA-1205 is well suited for optical focusing and other micropositioning applications such as scanning interferometry, surface structure analysis, disk drive testing, autofocus systems, confocal microscopy, bio-technology, semiconductor test equipment.

Motion Control – Open Aperture Voice Coil Motor

Van Nuys, CA – Motion Control – Low inertia hollow core voice coil or moving coil linear motors from Moticont feature high acceleration, precise positioning to less than one micron (0.00004 in.), high reliability, and low cost. The cleanroom friendly, non-commutated motors are available in 23 off-the-shelf standard sizes, Moticont hollow core voice coil linear motors have open apertures of 0.125 in. (3.2 mm) to 2.000 in. (50.8 mm).

Motion Control Technology Newsletter – SLT Dry Lube

Motion Control Technology Newsletter E. Longmeadow, MA – Lubrication, Lubrication Systems have always been a required – but less than desirable – facet of bearing life. What if you could go Lube-Free. For more information, Call John Tarbell at 800-513-3163, Fax: 413-525-3735 or E-Mail: JTarbell@lm76.com!

Motion Control Technology Newsletter – Tubular Solenoids

Motion Control Technology – Van Nuys, CA – Magnetic Sensor Systems (MSS) has released their S-20-100X model of Pull Type Tubular Solenoids. Their S-20-100X series of solenoids features 18 different solenoids to select from based on the Voltage, Duty Cycle, Force and Stroke requirement of the user.

MSS Solenoids coils typically utilize Class “F” 23 to 40 AWG (American Wire Gauge) windings with Class “A” insulation for better protection of the solenoid during longer duty cycles.

Motion Control Technology – Multi-axis Motion Controllers

Van Nuys, CA – Motion Control Technology – Complementing the OES (Optimal Engineering Systems Inc.) growing line of single and multi-axis positioning stages is the Allegra Series of Stored Program Motion Control Systems Controllers. The Allegra Series of Controllers is available as a desktop (pictured) or 19 inch rack mount system.

Motion Control – Linear Focus Actuator features 200 Nanometer repeatability!

Forestville, CA, – — Motion Control – This Custom LFA-2003 Linear Focus Actuator Features: 20 millimeter clear aperture, 3 millimeters linear motion, 200 nanometer position repeatability, Flexure guidance system, ‘C’ mount lens adapter, integrated coil temperature sensor, direct SCA814 Servo Controlled Amplifier compatibility, 74mm x 61mm, 690 grams.

Motion Control – Servo Drive

Motion Control – ADVANCED MOTION CONTROL AND POWER ALL IN ONE COMPACT PACKAGE

Vaughan, Ontario, Canada — Motion Control – Advanced Motion Controls (AMC), a US leading provider of servo amplifiers, is proud to announce the release of the FE060-25-IPM FlexPro® series servo drive. This state-of-the-art drive is designed to provide advanced control and power in one compact package, making it the perfect choice for a wide range of industrial and commercial applications.

Motion Control – Hybrid Ceramic Bearings Application

E. Longmeadow, MA –Motion Control – CERAMICSPEED Hybrid Radial Bearings are designed for environments of high humidity, have been approved in accordance with FDA 21 CFR (Code of Federal Regulation covering medicine and food), and have an EC No. 1935/2004 authorization. Superior life and performance when compared to bearings made from just stainless steel, these Bearings feature very smooth ceramic balls that will not deform or spall under high loads, and synthetic material ball cages.

Motion Control – Long Travel Linear Stages

Van Nuys, CA – — Motion Control – A series of long travel, low cost, low profile, motorized, profile rail positioning stages are now available from Optimal Engineering Systems, Inc. (OES). The AQ140 Series of linear stages are available off-the-shelf in travel lengths of: 600 mm, 700 mm, 800 mm, 900 mm, and 1000 mm. These high precision stages can be ordered with a Two-Phase Stepper Motor (pictured) which feature resolutions of 2 micron and 1.25 micron (achieved with a 10 or 20 micro-steps per step stepper motor driver), and up to 80 mm per sec of travel.

Motion Control – Tutorial – Solenoid Construction

Solenoid Construction

A Solenoid is a long wire, wound with a helical pattern, usually surrounded by a steel frame, having a steel core inside the winding.

When carrying a current “i “, the Solenoid becomes an electro-mechanical device, in which electrical energy is converted into mechanical work.

Motion Control – 200 Nano Meters  Repeatability Actuator!

Forestville, CA, – — Motion Control – This LFA-0604 Linear Focus Actuator: Flexture guidance system, 6 millimeter clear aperture, 4 millimeters of linear motion, 90 G’s acceleration (no load), 200 nanometers positioning repeatability, non-contact electro-optic position sensor, direct SCA814 Servo Controlled Amplifier compatibility, 38mm x 24mm, 80 grams

Motion Control – EtherNet/IP Servo Drives

Vaughan, Ontario, Canada — Motion Control – The FlexPro® drive series is AMC’s latest family of digital servo drives designed for high power, small size, and reliable servo motor control. The drive architecture allows for higher power densities while still maintaining reliability and versatility. The advanced processing and storage capabilities ensure that the drives are more intelligent and operationally flexible than ever before

Linear Motion Actuator – 1.0 Inch Diameter Voice Coil Motors!

Van Nuys, CA – Motion Control – Moticont has added a 0.750 in. (19.1 mm) diameter (smaller than a US Quarter) Linear Voice Coil Motor, to their expanding line of voice coil or moving coil motors. The LVCM-019-048-02 Linear Voice Coil Motor is a true servo motor featuring zero cogging, high accuracy, and high repeatability when operated in a closed position loop. Voice Coil Motors (also referred to as actuators) are clean, quiet, efficient, brushless high speed linear servo motors. This small LVCM-019-048-02 diameter actuator has a 1.500 in (38.1 mm) stroke length and a high-force-to-size ratio of 7.4 oz (2.1 N) and a peak force of 23.5 oz. (6.5 N) at 10% duty cycle.

This efficient, low inertia, high acceleration, brushless, high speed linear motor has zero cogging and features high accuracy, and high repeatability. It is ideal for: Work holding and clamping, medical devices, haptic feedback, assembly, testing, laser machining and drilling, wafer handling, optical focusing, dynamic vibration absorption, scanners and laser beam steering and filtering.
