Editor-Publisher Motion Control – Dual-axis Pitch and Roll Stages!
 |
Van Nuys, CA – Motion Control – The precise measurements of angles and the curvature of objects are easily determined using two new Pitch and Roll stages just introduced by OES (Optimal Engineering Systems, Inc.). The PR100-45-01 (pictured) is driven by stepper motors and the PR100-45-02 is driven by brushless servo motors with quadrature incremental optical encoders.
The Pitch axis (lower stage) is a high precision goniometer stage which features preloaded cross roller guides and a high ratio worm drive for smooth motion over a range of travel of +/- 45 degrees. It has a typical accuracy of 0.05 degrees and repeatability of +/- 0.01 degrees. Additionally, this axis has end-of-travel limit switches.
The 100 mm diameter Roll axis (upper stage) has a 180:1 gear ratio for smooth motion and has a precise pattern of threaded holes for fixtures or tooling. This axis has an accuracy of 0.05 degrees and repeatability of +/- 0.01 degrees. The Roll axis has a Home signal for initialization. Each axis features a calibrated scale to visually display the angle. The maximum speed with stepper motors is 14 degrees/second and 45 degrees/second with servo motors. The knobs of the stepper motors can be replaced with optional optical encoders for position verification.
The resolution of the PR100-45-01 stepper motor driven duel-axis stage depends on the resolution of the step motor driver resolution or the optical encoder if a servo motor is used. A resolution of 0.001 degrees equivalent to 3.6 arc-sec can be achieved using a10 micro-steps per step stepper motor driver or an encoder with a resolution of 500 cycles per revolution.
The PR100-45-02 that features servo motors and optical quadrature encoders are used for very precise closed loop operation and greater speeds. The PR100-45-01 and -02 stages can be ordered plug-and-play with a fully a compatible multi-axis motion controller from OES.
About OES – Optimal Engineering Systems, Inc. (OES) is a manufacturer of motion control products including: Stepper motor controllers and drivers, solenoid electronics, and positioning stages and slides. Applications include: Animation, automated assembly systems, automation, CNC machines, flight simulation, inspection systems, linear and rotary stages, machine tools, medical devices, motion control camera boom systems, optical comparators, CMMs, pan-tilt gimbals, PCB assembly & inspection, pick-and-place, positioning stages, robotics, scanners, security cameras, telescope drive mechanisms, time-lapse photography and winders.
Some of the industries OES serves are: Aerospace, Astronomy, Chemical, Communications, Educational Institutes, University, Colleges, Government Agencies, National Labs, Manufacturing, Medical, Metrology, Military, Motion Control, Museum, News Agencies, Semiconductor and Test Equipment. Optimal Engineering Systems, Inc’s. competitive advantage is its state-of-the-art in-house manufacturing facility in North America enabling OES to supply clients with custom designed orders or high volume just-in-time deliveries globally.
For additional information, contact sales team at: OES, 6901 Woodley Ave.; Van Nuys, CA 91406; Telephone: 888-777-1826 or +1 818-222-9200, FAX +1 818-436-0446 or E-Mail: sales@oesincorp.com or visit the website at http://www.oesincorp.com
